| Production
Speed: |
1-30 loads per hour (Single Turntable)
NOTE: Process rates will vary with load size, number
of wraps & forklift load/unload time |
 |
| Load Capacity: |
Maximum load weight: 4,000# dynamic – 10,000#
static
Maximum load size: 56” W x 56” L (79”
max. load
diagonal) x
75” H (plus up to 4” top overlap) |
|
| Turntable: |
48” octagonal 5/16” thick formed steel plate
turntable
4 point caster support system
Turntable height less than 11” from floor
ANSI # 50 direct chain drive c/w chain tensioner
3-12 RPM rotational speed c/w soft start acceleration
1/2 HP AC variable speed motor
Final revolution deceleration and positive stop alignment
Front and back forklift ports for easy movement
Accu-Count exact turntable positioning system for
additional film savings! |
|
| Film Carriage Elevator: |
1/2 HP AC variable speed motor
ANSI #40 direct chain drive c/w shock dampener &
Anti-
Fall Safety Device
Maintenance free carriage guidance system |
|
| Film Delivery System: |
Stretch roller with manually adjusted caliper brake
web
tensioning system
Standard 20” roll width, 10” diameter
Carriage Descent Obstruction Safety Shut-Off
Device
Side mounted film carriage for operator convenience
and
safety |
|
| Film Capacity: |
Accepts
all commercial films wound on 3” diameter
cores
x 20” width
Accommodates damaged cores |
|
| Control Features: |
Electronic controls with LCD operator interface
Power Off – On – Reset switch & Power
On indicator
light
Single button Auto Wrap Cycle Start/Pause
Cycle Pause for applying top sheets
Reinforce Wrap control for mid-wrapping
Base or Top Wraps First program
Up Only or Up/Down wrap program
Emergency Stop button
Turntable Jog button
Film Carriage Lower & Raise buttons
Separate film carriage raise & lower speed controls
Operator programmable turntable speed control
Triple beam automatic load height detection sensor for
dark or shiny loads
Separate 1 to 12 revolution top & bottom wrap control
A – B – C wrap program selector with capability
to input and store unique
wrapping parameters for each program |
|
| Structural Features: |
All
structural steel construction
Forklift truck portable base structure
design – lifting
tubes
included for front and rear access
Structural steel tube machine tower with sheet metal
covers
Electro-static powder coated paint
finish |
|
Electrical Requirement:
|
115 Volts 1 Phase 60 Hz 10 Amps |
