| Production
Speed: |
 1-30
loads per hour
NOTE: Process rates will vary with load size,
number of wraps & forklift load/unload
time |
|
| Load Capacity: |
Maximum
load weight: Unlimited (floor supported)
Maximum load size: 50” W x 50” L
(71” max. load
diagonal) x 86” H (plus up to 4” top
overlap) |
|
| Rotary Arm: |
Double
flange bearing support system
Twin V-belt drive pulleys with belt
tensioner
1-12 RPM rotational speed c/w soft
start acceleration
Final revolution deceleration and
positive stop alignment
1/2 HP DC variable speed motor |
|
| Film Carriage Elevator: |
1/2
HP DC variable speed motor
Direct flat belt drive system
Maintenance free 12 point carriage
guidance system |
|
| Film Delivery System: |
Super
Rapid Thread™ 20” capacity pre-stretch
carriage
with Patent Pending pressure balanced nip
roller system
1/2 HP DC variable speed motor
Fully electronic dynamic dancer corner compensation
33 to 313% fixed stretch capability
Pre-stretch ratio variable by easy
sprocket change
Rapid Thread™ Safety Door with
auto power cut-off
switch |
|
| Control Features: |
Simple
to operate
PANASONIC PLC
Power Off – On – Reset
switch & Power
On indicator light
Single button Auto Wrap Cycle Start/Pause
Cycle Pause for applying top sheets
Base or Top Wraps First program
Reinforce Wrap control for mid-wrapping
Up Only or Up/Down wrap program
Emergency Stop button
Rotary Arm Jog switch
Film Carriage Lower/Raise switch
Film tension (Force-to-Load) control
Separate film carriage raise & lower
speed controls
Variable rotary arm speed control
Rotary arm and carriage elevator dynamic
braking system
Triple beam type auto load height
sensing photo-eye,
detects
dark or shiny loads
Separate 1 to 9 revolution top & bottom
wrap control
NEMA 12 control panel enclosure
Dust tight slip ring assembly
Non-proprietary UL/CSA approved components |
|
| Safety Features: |
Rotary Arm Obstruction Emergency
Safety Stop
Sensor |
|
| Structural Features: |
All
structural steel construction
Integral structural steel wall/floor
mounting stand
Electro-static powder coated paint
finish |
|
Electrical Requirement:
|
115
Volts 1 Phase 60 Hz 15 Amps |
