| Production
Speed: |
 1-35
loads per hour
NOTE: Process rates will vary with load size,
number of wraps & load/unload time |
 |
| Load Capacity: |
Maximum
load weight: Unlimited (floor supported)
Maximum load size: 50” W x 50” L
(71” max. load
diagonal) x 86” H (plus up to 4” top
overlap)
Minimum load size: 24” W x 24” L
x 24” H |
|
| Rotary Arm: |
Double
flange bearing support system
Twin V-belt drive pulleys with belt
tensioner
1-12 RPM rotational speed c/w soft
start acceleration
Final revolution deceleration and
positive stop alignment
1/2 HP DC variable speed motor |
|
| Film Carriage Elevator: |
1/2
HP DC variable speed motor
Direct flat belt drive system
Maintenance free 12 point carriage
guidance system |
|
| Film Delivery System: |
Super
Rapid Thread™ 20” capacity pre-stretch
carriage
with Patent Pending pressure balanced nip
roller system
1/2 HP DC variable speed motor
Fully electronic dynamic dancer corner
compensation
33 to 313% fixed stretch capability
Pre-stretch ratio variable by easy
sprocket change
Rapid Thread™ Safety Door with auto
power cut-off
switch |
|
| Control Features: |
PANASONIC
PLC with Touchscreen Operator Interface
Power Off – On – Reset
Switch & Power
On indicator
light
Single button Auto Wrap Cycle Start/Pause
Cycle Pause for applying top sheets
Reinforce Wrap control for mid-wrapping
Emergency Stop button
Rotary Arm Jog button
Film Carriage Lower/Raise buttons
Film Clamp Open/Close button
Film tension (Force-to-Load) control
Separate film carriage raise & lower
speed controls
Variable rotary arm speed control
Triple beam auto load height sensing
photo-eye, detects
dark
or shiny loads
Separate 1 to 12 revolution top & bottom
wrap control
Selectable Reduced Bottom Film Force
parameter for
wrapping bottom of load
A – B – C Wrap Program
selector with capability to input
and
store unique wrapping parameters for each
program
Pendant Start/Stop push-button station
for remote
operator
control – optional lanyard or wireless
remote
control available
Stack-light beacon indicates run,
clear or fault conditions
Rotary arm and film carriage elevator
dynamic braking
NEMA 12 control panel and junction
boxes
Dust tight slip ring assembly
Non-proprietary UL/CSA approved components |
|
| Automation Features: |
“All Electric – No Pneumatics
Required”
Electro-mechanically actuated film
clamp mechanism
Electro-mechanically actuated film
tail cut/wipe arm
mechanism
Ni-chrome impulse hot wire film cut
off c/w automatic
periodic
cleaning cycle |
|
| Structural Features: |
All
structural steel construction
Integral structural steel wall/floor
mounting stand
Electro-static powder coated paint
finish |
|
| Safety Features: |
Rotary
Arm Obstruction Emergency Safety Stop
Sensor |
|
Electrical Requirement:
|
115
Volts 1 Phase 60 Hz 15 Amps |
