| Production Speed: |  1-15 loads per hour
NOTE: Process rates will vary with load size; number of
wraps & forklift load/unload time |
 |
| Load Capacity: | Maximum load weight: 3,000# dynamic – 8,000# static
Maximum load size: 48” W x 48” L x 75” H (68” Max.
load diagonal)
NOTE: Maximum load size shown is the largest load
PUP will wrap – no exceptions |
|
| Turntable: | 57” Diameter 5/16” thick laser-cut steel plate
18 point turntable support system
Turntable height 2-1/4” from floor
ANSI # 50 Direct Chain Drive c/w chain tensioner
1 - 9 RPM rotational speed c/w soft start acceleration
1/3 HP VDC variable speed gear-motor
Safety surround ring encloses turntable |
|
| Film Carriage Elevator: | 1/8 HP VDC variable speed gear-motor
Direct flat belt drive system
4 point “V” wheel carriage guidance system with side
thrust rollers |
|
Film Delivery
System /
Film Capacity: |
Manually
adjusted friction brake web tensioning system
Side mounted film
carriage for operator convenience and
safety
Accepts hand-wrap
to machine grade films, 12” to 20” roll
width, up to 10” diameter |
|
Control Features:
– Manual Model
LP 550-M |
Simple to operate
Power On / Emergency Stop button
Turntable Jog / Run switch
Film Carriage Lower / Raise switch
Film carriage variable speed control
Turntable variable speed control
Non-proprietary UL/CSA approved components |
|
Control Features:
– Semi-Automatic
Models LP 550-SA& LP 550-SAP |
Simple to operate
Power On / Emergency Stop button
Turntable Jog / Cycle Start switch
Film Carriage Lower / Raise switch
Turntable variable speed control
Film carriage variable speed control
Separate top & base wrap duration timers
Adjustable top limit switch wrap height control
Auto Load Height Sensing photo-eye (on LP 550-SAP
model
only)
Non-proprietary UL/CSA approved components |
|
| Structural Features: | Formed steel base construction
Formed steel metal tower
Forklift truck portable base design – pick-up angles
included |
|
Electrical Requirement:
| 115 Volts 1 Phase 60 Hz 10 Amps |
